DIAMOND SERIES CENTER LINK

Name: DIAMOND SERIES CENTER LINK
SKU: RP26289
Price: 195.42 USD
Availability: InStock

(0) No Reviews yet

Details

1 Each, 1 Per Vehicle.

Full Ball Stud Pitman Arm end
Greaseable
Self aligning no bind design
Low friction

Specifications

Attribute	Description
Shaft Diameter	0.918
Length Center to Center Studs	23.250
Number of Holes	2
Hole Sizes	0.493
Pitman Arm End to Hole 1	3.438
Pitman Arm End to Hole 2	17.313
Pitman Arm End to Hole 3	-
Pitman Arm End to Hole 4	-
Pitman Arm End to Hole 5	-
Adjustable	No
Greaseable	Yes
Package Contents	1 Center Link, 2 Castle Nuts, 2 Cotter Pins, 2 Felt Washers, 2 Grease Fittings

Applications

Year	Make	Model	Location	Comment	Application
1964	Buick	Skylark	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1964	Buick	Special	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1964	Buick	Sportwagon	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1964	Chevrolet	Chevelle	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1964	Chevrolet	El Camino	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1964	Chevrolet	Malibu	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1965	Oldsmobile	442	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1966	Oldsmobile	442	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1967	Oldsmobile	442	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1964	Oldsmobile	Cutlass	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1965	Oldsmobile	Cutlass	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1966	Oldsmobile	Cutlass	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1967	Oldsmobile	Cutlass	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1967	Oldsmobile	Cutlass Supreme	FRONT	This is a Rare Parts Inc. Diamond Series Part.	RWD
1964	Oldsmobile	F85	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1965	Oldsmobile	F85	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1966	Oldsmobile	F85	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1967	Oldsmobile	F85	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1964	Oldsmobile	Vista Cruiser	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1965	Oldsmobile	Vista Cruiser	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1966	Oldsmobile	Vista Cruiser	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1967	Oldsmobile	Vista Cruiser	FRONT	W/ 13/16" Diameter Center Link; This is a Rare Parts Inc. Diamond Series Part.
1964	Pontiac	GTO	FRONT	3.438" & 17.313" Inner Tie Rod Holes; This is a Rare Parts Inc. Diamond Series Part.
1965	Pontiac	GTO	FRONT	3.438" & 17.313" Inner Tie Rod Holes; This is a Rare Parts Inc. Diamond Series Part.
1964	Pontiac	LeMans	FRONT	3.438" & 17.313" Inner Tie Rod Holes; This is a Rare Parts Inc. Diamond Series Part.
1965	Pontiac	LeMans	FRONT	3.438" & 17.313" Inner Tie Rod Holes; This is a Rare Parts Inc. Diamond Series Part.
1964	Pontiac	Tempest	FRONT	3.438" & 17.313" Inner Tie Rod Holes; This is a Rare Parts Inc. Diamond Series Part.
1965	Pontiac	Tempest	FRONT	3.438" & 17.313" Inner Tie Rod Holes; This is a Rare Parts Inc. Diamond Series Part.
